Contains Starts With Exact Match Home › Deep Groove Ball Bearings Single Row › 6301-H-2RSR-C3 FAG 6301-H-2RSR-C3 FAG

Deep Groove Ball Bearings Single Row

Price on request in basket Change on quote list Change Add to basket Change Add to quote list Update quote list on pcs Or change the QTY ...or add to basket ... or signup for an account

84 pcs in stock

• This product is available from stock
• Shipment until 18:00 CET on business days
• Payment by invoice possible
• Track your order with track & trace
• Official Schaeffler distributor

Loading equivalents

Specifications

• Availability 84 pcs
• Brand FAG
• Item Number 6301-H-2RSR-C3 FAG
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 12
• Outer (D) MM 37
• Width (B) MM 12
• Inner (d) Inch 0.4724
• Outer (D) Inch 1.4567
• Width (B) Inch 0.4724
• Weight (kg) 0.061

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play C3 Internal Play (Higher than Cn)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 12
• Radial Static Load Rating C0r (N) 3500
• Radial Dynamic Load Rating Cr (N) 7690
• Limiting speed (n G) 13400
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearings 63..-H-2RSR, main dimensions to DIN 625-1, lip seals on both sides

Suffix description

• H Basic Quality
• 2RSR Rubber Seals At Each Side Of The Bearing
• C3 Internal Clearance Larger Than Normal

Downloads & Links

• Link to manufacturer
