Skip to content Asynchronous DC-DC controller and driver for automotive Xenon HID lamps

The ASIC generates the required voltages for ignition, startup and normal operation of the lamps. Included are the igniter, H-bridge and the H-bridge driver, which operates the lamp in AC for higher durability.

A power regulation loop generates an accurate PWM power control to the lamp up to 35W. The loop stability of the whole system is analyzed using Matlab.

KEY FEATURES

  • Drive and control the ballast for a XENON HID head lamp from a 12V battery
  • Asynchronous DC-DC controller
  • Over/under-voltage, over-current and over-temperature protection
  • EMC, Schaffner pulse immunity (ISO 7637-2)
  • Max. 36V power supply
  • -40°C to 150°C
  • 0.35um BCD 50V technology

Why choose ICsense for your next automotive ISO26262 ASIC development ?

ICsense is a trusted partner in the development and supply of automotive-grade ASICs for highly reliable solutions for safety-critical applications (ASIL B/C/D). Since 2004, the mixed-signal ASICs of ICsense are used in battery management, sensor interfaces, HV drivers and automotive communication. With advanced design methodologies (6σ), high test coverage, and stringent production screening (PAT, SBIN, Vstress, Iddq), we guarantee long-term reliability.

Our values:

  • Over +20 years of expertise in automotive ASIC development
  • Exclusive development and supply. IP owned by the customer
  • Development flow acc. Functional Safety ISO26262
  • One of the largest design teams in Europe
  • In-house mass production testing (ATE)
