Xr20cx-5n1c1 Dixell Controller, Prime Cx Refrigeration Controllers Digital Temperature Controller

Negotiable

1 Piece (MOQ)

Product Details

Customization:	Available
Installation Type:	Duct Type
Sensing Type:	Resistive

Contact Me Chat Shenzhen Ruifujie Technology Co., Ltd. Manufacturer/Factory, Trading Company, Other

360° Virtual Tour

What's your impression of this company? review now Diamond Member Since 2011

Suppliers with verified business licenses

Audited Supplier

Audited by an independent third-party inspection agency

Management System Certification ISO 9001 OEM/ODM Availability Yes

• On-Site Scanning
• Precise Digital Duplicate
• Angle Unlimited

•
•
•
•

Add Inquiry Basket to Compare Add Inquiry Basket to Compare

•
•
•
•

1/4 Find Similar Products

Product Description

Company Info.

Basic Info.

Model NO. XR20CX-5N1C1 Contact Contactless Output Signal Type Digital Type Production Process Normal Wirewound Material Plastic Measuring Medium Temperature IP Rating IP20 Certification CE Customized Non-Customized Types of Control Intelligent Temperature Control Regulator Measurement Object Cold Storage, Cold Storage Control Type - 50 to + 150 ºC The Size of Hole 71*29mm Transport Package Carton Box Specification CE SGS Trademark Dixell Origin Italy HS Code 8414301000 Production Capacity 5000PCS/Year

Product Description

Dixell Controller,Prime CX Refrigeration Controllers for ac ,cold room use Dixell Controller : Xr20cx-5N1C1 DIGITAL CONTROLLER WITH "OFF CYCLE" DEFROST Generals Power supply: 110, 230Vac Probe inputs Thermostat: NTC Digital inputs Alarm, start defrost, AUX, door switch, pressure switch: Configurable Relay outputs Compressor: 8A, 20A optional Other Hot Key: Present Buzzer: Optional (available only with 8A compr. Relay)

The new PRIME series in CX format, is an innovative range of products that Dixell has introduced to the market for both heating and L.T., N.T. refrigeration. The CX family (32x74mm) has new functions plus an innovative and attractive design. The revolutionary introduction of 6 keys allows the user direct access to all main functions rapidly and intuitively, while the display with illuminated icons allows an instant view of the machine's status. All the instruments in CX format incorporate the latest know how and technology, both in software and hardware to ensure the highest standards of performance. Easy and intuitive installation 9 - 40Vdc power supply for refrigerated trucks (for models with 8A compressor) Energy saving cycles triggered via a digital input; for example, it is possible to work at a set point that is different from the normal one in order to, for instance, accumulate cold when electric power is cheaper Continuous cycle with dedicated set; it allows the machine to work during rapid cooling cycles to achieve the right product temperature Regulation stop by auxiliary probe (beer dispenser applications); it is possible to supervise the tube temperature, stopping the compressor when the temperature becomes too low, and restarting when the correct values have been restored Regulation re-start with door switch alarm Max and Min temperature or HACCP function Digital input configurable as probe Virtual probe for air on / air off application; used in multideck applications where it is important to regulate temperature using the average of 2 temperatures Dual thermostat function; is available, on demand, in applications such as white or red wine rooms where it is necessary to maintain 2 different temperatures Condenser temperature management to prevent critical situations in the system TTL serial connection for monitoring systems (using XJ485CX) Connection for remote display X-REP (excludes TTL)

Thermostat and Controllers with " OFF CYCLE" DEFROST for Normal, Medium and Low Temperature XR10CX Thermostat with heating or cooling action. XR20CX Controller for NT with "off cycle" defrost. XR30CX Controller for NT with "off cycle" defrost and additional configurable relay. XR35CX Controller for NT with "off cycle" defrost and additional configurable relay and RS485. XR36CX 2 set point controller for NT with "off cycle" defrost; created for applications where is necessary to maintain 2 different temperature such as white/red wine rooms Controllers for Normal, Medium and Low Temperature XR40CX Digital controller for MT and LT with electrical or hot gas defrost. XR50CX Controller for MT and LT with electrical or hot gas defrost and auxiliary relay. XR56CX 2 set point controller for MT and LT with electrical or hot gas defrost and auxiliary relay; created for applications where is necessary to maintain 2 different temperature such as white/red wine rooms

FEATURES XR10CX XR20CX XR30CX XR35CX XR36CX Power supply 12, 24Vac/dc, 24, 110, 230Vac 9 ÷40Vdc 12, 24Vac/dc, 24, 110, 230Vac 9 ÷40Vdc 12, 24Vac/dc, 24, 110, 230Vac 9 ÷40Vdc 24, 110, 230Vac 12, 24Vac/dc, 24, 110, 230Vac 9 ÷40Vdc Display : number digits ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. Probe inputs Thermostat NTC / PTC NTC / PTC NTC / PTC NTC / Pt1000 NTC / PTC Thermostat 2 - - - - NTC / PTC Defrost - - - NTC / Pt1000 - Condenser NTC/PTC on hot key NTC/PTC on hot key NTC/PTC on hot key NTC / Pt1000 NTC/PTC on hot key Digital inputs Alarm,start defrost, AUX, door switch, pressure switch, probe Configurable Configurable Configurable Configurable Configurable Alarm,start defrost, AUX, door switch, pressure switch - - - Configurable - Relay outputs Compressor 8A/20A 8A/20A 8A/20A 8A/16A 8A/20A Compressor 2, Thermostat 2 - - - - 8A Defrost - - - - - Fan - - - - - Light or Alarm - - 8A 8A - Anti - sweat - - - - - Other Hot key / Programming Tool Kit output Present Present Present Present Present Remote display output X - REP option X - REP option X - REP option X - REP option X - REP option Serial output TTL TTL TTL TTL/RS485 TTL Buzzer available only with compressor = 8A Real time clock - - option option -

FEATURES XR40CX XR50CX XR56CX Power supply 12, 24Vac/dc, 24, 110Vac, 230Vac 9 - 40Vdc 12, 24Vac/dc, 24, 110Vac, 230Vac 9 - 40Vdc 24, 110Vac, 230Vac 12, 24Vac/dc, 24, 110Vac, 230Vac 9 - 40Vdc 24, 110Vac, 230Vac Display : number digits ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. Probe inputs Thermostat NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / PTC Thermostat 2 - - - NTC / PTC NTC / PTC Defrost NTC / PTC NTC / PTC NTC / PTC - - Condenser NTC / PTC on hot key Digital input Alarm,start defrost, AUX, door switch, pressure switch, probe Configurable Configurable Configurable Configurable Configurable Alarm,start defrost, AUX, door switch, pressure switch - - - - - Relay outputs Compressor 8A/20A 8A/16A 20A 8A/16A 20A Compressor 2, Thermostat 2 - - - 8A 8A Defrost 8A 8A 8A - - Fan - - - - - Light or Alarm - 8A 5A 8A 5A Anti - sweat - - - - - Other Hot key / Programming Tool Kit output Present Present Present Present Present Remote display output X - REP option X - REP option X - REP option X - REP option X - REP option Serial output TTL TTL TTL TTL TTL Buzzer available only with compressor = 8A Real time clock - - - - -

FEATURES XR60CX XR64CX XR70CX Power supply 12, 24Vac/dc, 24,110Vac,230Vac 9 - 40Vdc 24,110Vac, 230Vac 24,110Vac, 230Vac 12Vac/dc 24,110Vac, 230Vac 12Vac/dc Display : number digits ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. Probe inputs Thermostat NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / PTC Thermostat 2 - - - - - - Defrost NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / PTC Defrost 2 - - NTC / PTC NTC / PTC - - Condenser NTC / PTC on hot key Digital input Alarm,start defrost, AUX, door switch, pressure switch, probe Configurable Configurable Configurable Configurable Configurable Configurable Alarm,start defrost, AUX, door switch, pressure switch - - - - - - Relay outputs Compressor 8A/16A 20A 8A/16A 16A 8A/16A 16A Compressor 2, - - - - - - Thermostat 2 - - - - - - Defrost 8A 8A 8A 16A 8A 16A Defrost 2 - - 8A 16A - - Fan 8A 5A 5A 16A 5A 16A Light or Alarm - - - - 8A 16A Anti - sweat - - - - - - Other Hot key / Programming Tool Kit output Present Present Present Present Present Present Remote display output X - REP option Serial output TTL TTL TTL TTL TTL TTL Buzzer available only with compressor = 8A Real time clock - - - - option option

FEATURES XR71CX XR72CX XR75CX XR77CX Power supply 24, 110Vac, 230Vac 12Vac/dc 24, 110Vac, 230Vac 12Vac/dc 24, 110Vac, 230Vac 230Vac Display : number digits ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. ± 3 d.p. Probe inputs Thermostat NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / Pt1000 NTC / PTC Thermostat 2 - - - - - - Defrost NTC / PTC NTC / PTC NTC / PTC NTC / PTC NTC / Pt1000 NTC / PTC Defrost 2 - - - - - - Condenser NTC / PTC on hot key NTC / Pt1000 NTC / PTC Digital input Alarm,start defrost, AUX, door switch, pressure switch, probe Configurable Configurable Configurable Configurable Configurable Configurable Alarm,start defrost, AUX, door switch, pressure switch - - - - Configurable Configurable Relay outputs Compressor 8A/16A 16A 8A/16A 16A 8A/16A 16A Compressor 2, Thermostat 2 - - 8A 16A - - Defrost 8A 16A 8A 16A 8A 8A Defrost 2 - - - - - - Fan 5A 16A 5A 16A 5A 5A Light or Alarm - - - - 8A 8A Anti - sweat 8A 16A - - - - Other Hot key / Programming Tool Kit output Present Present Present Present Present Present Remote display output X - REP option Serial output TTL TTL TTL TTL RS485 RS485 Buzzer available only with compressor = 8A Real time clock - - - - option Present
