Home
Metals
Copper
CW024A (C106) Sheet & Tube

Range

Product Form	Imperial Sizes	Metric Sizes
Sheet HH 2m x 1m	-	0.55mm - 6.0mm
Sheet HH 2.5m x 1.25m	-	1.2mm - 10.0mm
Sheet HH 4' x 2'	24 swg - 10 swg, 3⁄16"	-
Tube	1⁄4" OD - 2 1⁄2" OD	-

If you do not see what you are looking for, please contact your local service centre with your specific requirements.

Related Specifications

C106/CW024A copper corresponds to the following designations but may not be a direct equivalent:

UNS C12200
ISO Cu-DHP

Properties

Chemical Composition

CW024A

EN 1652

Chemical Element	% Present
Copper (Cu)	99.90 - 0.00
Others (Total)	0.00 - 0.10

Mechanical Properties

Sheet 0.2mm to 15mm thick

EN 1652

Mechanical Property	Value
Proof Stress	50-340 MPa
Tensile Strength	200-360 MPa
Elongation A50 mm	50-5 %
Hardness Vickers	40 to 110 HV

General Physical Properties

Physical Property	Value
Density	8.92 g/cm³
Melting Point	1083 °C
Thermal Expansion	16.9 x10-6/K
Modulus of Elasticity	117 GPa
Thermal Conductivity	391.2 W/m.K
Electrical Resistivity	0.0203 x10-6 Ω .m

Applications

Refrigeration plant
Gutters and roofing
Gas plants
Hydraulic, air and oil lines
Air conditioning and refrigeration
Heater units and burners tubes consumer
Plumbing pipe and fittings
Chemical pipe work
Marine and general engineering fasteners
Water and gas installations and tubings
Architectural metalwork
Masonry fixings

Characteristics

Very good electrical and thermal conductivity values
Non-magnetic & spark resistant
Good corrosion resistance
Excellent formability
Excellent joining properties
Ideal for plating and polishing
Not susceptible to hydrogen embrittlement

Additional Information

Weldability

Deoxidation of C106/CW024A improves embrittlement resistance during welding.

Brazing and soldering are both excellent joining methods for C106/CW024A. Gas shielded arc welding is also excellent. Oxyacetylene welding and butt welding are good. Welding methods not recommended include:

Coated metal arc welding
Spot welding
Seam welding

Corrosion Resistance

Corrosion resistance is either good or excellent in most environments and atmospheres other than those containing ammonia ions.

Heat Treatment

Solution treatment or annealing can be done by rapid cooling after heating to 370-650°C.

Machinability

This alloy has a machinability rating of 20 when Brass CZ121/CW614N is 100.

Cold Working

C106/CW024A has an excellent response to cold working.

Hot Working

With forging of brass rated as 100, the hot forgeability of C106/CW024A is rated at 65. Hot working temperatures should be between 760 and 870°C
