Small-size and precision motors｜Fans & Blowers｜Blower（Centrifugal fan）

G85G M CN

companies handling the product：Nidec Corporation

  • Print

General-use DC Sirocco fan

High value-added fan motor that wing structures that we have developed independently.

characteristics: High output and high efficiency Contact information for product inquiry Contact us

  • Product data

Product data

Basic information

sort by power source type DC
Size W111.94×H102.08 mm
Size W4.41×H4.02 inch
Length 20.2 mm
Length 0.80 inch
Operation temperature -10～65 ℃
Lifespan 20,000H（65℃）
Mass 100 g
Bearing Sleeve bearings
Companies handling the product NIDEC CORPORATION
Input
rated voltage 12 V11.4～12.6 V
Operating current 0.9 A
Rated input 10.8 W
Output
Rated speed 5000 min-1
Maximum air flow (m3/min) 0.84 m3/min
Maximum air flow (CFM) 29.6 CFM
Maximum static pressure(Pa) 379 Pa
Maximum static pressure(inchH2O) 1.52 inchH2O
Sound pressure(dB[A]) 38 dB[A]

Contact information for product inquiry

For inquiries related to Nidec products incorporated into end products manufactured by other companies, please contact the end product manufacturer. For contractual reasons, Nidec is unable to repair, replace, quote or suggest replacement products for components that have been designed specifically for a particular end product manufacturer.

Inquiry by e-mail

  • Discuss development/design of a new product
  • Request a quotation
  • Confirm the specifications of a product
