You are using an out of date browser. It may not display this or other websites correctly.You should upgrade or use an alternative browser. Steam Tables - g vs. fg

• Thread starter Thread starter mechgirl
• Start date Start date Apr 6, 2010

Help Support Engineer Boards:

Donate This site may earn a commission from merchant affiliate links, including eBay, Amazon, and others. M

mechgirl

Well-known member

Joined Apr 1, 2008 Messages 48 I know this is very basic, but I'm feeling like I'm missing something. Enthalpy as an example: I know that hf is enthalpy of saturated liquid, and hg is enthalpy of saturated vapor, and hfg = (hg - hf). I was working some vapor cycle problems last week, and from the steam tables, I would select hg for saturated steam at the given temp/pressure. Instead of hg, the solution selected hfg. I wish I could remember which problem, but I don't even remember which book I was working in. I just continued working problems at the time, but now I'm thinking about it and feeling confused. So, when would I select "fg" instead of "g" from the steam tables? I just feel so overloaded and tired and frustrated now, and like I'll never pass. A week ago, I was feeling pretty confident. Ugh. Ok, must refocus...

Firefly

Active member

Joined Dec 14, 2009 Messages 42 Location Charleston, SC hfg can be used as the latent energy and is used when finding the quality. B

Bman

Well-known member

Joined Jul 3, 2007 Messages 182 Location Ft Lauderdale, Fl fg is the enthalpy (entropy, etc) required for evaporation. There are certain equations that require you to use the "fg" such as the liquid-vapor equations- h = hf + (x)hfg where x is the quality. It's also used in other equations. I think you just need to be careful on what the question is asking and what you need to solve it. M

mechgirl

Well-known member

Joined Apr 1, 2008 Messages 48

Bman said: fg is the enthalpy (entropy, etc) required for evaporation. There are certain equations that require you to use the "fg" such as the liquid-vapor equations- h = hf + (x)hfg where x is the quality. It's also used in other equations. I think you just need to be careful on what the question is asking and what you need to solve it. Click to expand...

I know to use hfg for quality. I think this problem was a vapor power cycle, and I was finding the enthalpy of sat steam at a point. The solution used hfg while I used hg. They weren't finding quality, but said that hfg was the enthalpy of the steam at that point. It didn't make sense to me. What other times, besides finding quality, would I need hfg? Why would I select hfg instead of hg at a sat steam state point?

Baltimore Joe

Joe

Joined Jan 6, 2009 Messages 37 Location Lutherville Timonium

mechgirl said:

Bman said: fg is the enthalpy (entropy, etc) required for evaporation. There are certain equations that require you to use the "fg" such as the liquid-vapor equations- h = hf + (x)hfg where x is the quality. It's also used in other equations. I think you just need to be careful on what the question is asking and what you need to solve it. Click to expand...

I know to use hfg for quality. I think this problem was a vapor power cycle, and I was finding the enthalpy of sat steam at a point. The solution used hfg while I used hg. They weren't finding quality, but said that hfg was the enthalpy of the steam at that point. It didn't make sense to me. What other times, besides finding quality, would I need hfg? Why would I select hfg instead of hg at a sat steam state point? Click to expand...

I’d focus on phase change, specifically at the boiler or condenser. Here are locations when H fg may be applied, provided that the steam is going from a saturated liquid to a saturated gas or visa versa. G

gaidox

Project Engineer

Joined Mar 9, 2010 Messages 69 Location California

Baltimore Joe said:

mechgirl said:

Bman said: fg is the enthalpy (entropy, etc) required for evaporation. There are certain equations that require you to use the "fg" such as the liquid-vapor equations- h = hf + (x)hfg where x is the quality. It's also used in other equations. I think you just need to be careful on what the question is asking and what you need to solve it. Click to expand...

I know to use hfg for quality. I think this problem was a vapor power cycle, and I was finding the enthalpy of sat steam at a point. The solution used hfg while I used hg. They weren't finding quality, but said that hfg was the enthalpy of the steam at that point. It didn't make sense to me. What other times, besides finding quality, would I need hfg? Why would I select hfg instead of hg at a sat steam state point? Click to expand...

I’d focus on phase change, specifically at the boiler or condenser. Here are locations when H fg may be applied, provided that the steam is going from a saturated liquid to a saturated gas or visa versa. Click to expand...

Agree with them.. In addition to this, when things were little confusing with thermo phases, I recommend refreshing the rules for determining phases (merm 24.2), latent heats (merm 24.16), and thermo. properties (merm 24.25~30). These are good basic stuffs for thermo. I've noticed in samples exams that a lot of problems relies on the basics and will definitely helpful (to really master these) come exam day. I keep refreshing these when I got confused. $39.99 AWS Certified DevOps Engineer – Professional Exam Prep and Study Guide: 600+ Practice Questions with Answer Explanations | Hands-on Labs | Exam Tips | Comprehensive Coverage of All Exam Domains Amazon.com $35.00 Fundamentals of Physics I: Mechanics, Relativity, and Thermodynamics (Open Yale Courses) Amazon.com -29% $53.40 $75.00 CTS Certified Technology Specialist Exam Guide, Third Edition booksXpress $149.99 Industrial & Systems Engineering Professional Engineering Exam Study Guide IE PE Exam Study Guide -42% $149.00 $256.00 PPI FE Electrical and Computer Review Manual – Comprehensive FE Book for the FE Electrical and Computer Exam Kaplan North America -58% $85.00 $200.95 Fundamentals of Thermodynamics saveontextbooks1 -7% $11.14 $11.95 Thermodynamics (Dover Books on Physics) Amazon.com -10% $35.99 $39.95 Journeyman Electrician Exam Prep Study Guide: All-in-one Handbook to Pass the Test with Confidence Amazon.com $12.00 Understanding Thermodynamics (Dover Books on Physics) Amazon.com -40% $43.01 $72.00 Thermodynamics and Statistical Mechanics: An Integrated Approach (Cambridge Series in Chemical Engineering) Amazon.com Post reply
