1998 Volkswagen Caddy Wheel fitment guide Find out what wheels and tires fit 1998 Volkswagen Caddy Please select the 1998 Volkswagen Caddy vehicle modifications below and check tables to get wheel size, tire size, bolt pattern (PCD), rim offset and other wheel fitment parameters. If necessary, you can filter them by sales distribution region.

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003]

Generation Filter by region: Europe EUDM Russia+ RUS

Box

Pickup, 2d

Previous Next

1998 Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] - Modifications

Diesel:

1.7SDi I4 56hp 1.9 SDi I4 63hp 1.9D I4 63hp 1.9TDi I4 89hp

Petrol:

1.4MPi I4 59hp 1.6MPi I4 74hp

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.4MPi

59 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1995 .. 1999]
• Sales regions: Europe, Russia+
• Power: 59 hp | 44 kW | 60 PS
• Engine: 1.4 L, , Petrol

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 175/65R14 82T	5.5Jx14 ET35	33 - 37	118 4.65	7.3 16.2	2.1 30	OE
185/60R14 82T	6Jx14 ET38	127 5.00	7.6 16.7	2.1 30

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.6MPi

74 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1997 .. 2000]
• Sales regions: Europe, Russia+
• Power: 74 hp | 55 kW | 75 PS
• Engine: 1.6 L, , Petrol

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 185/60R14 82T	6Jx14 ET38	36 - 40	127 5.00	7.6 16.7	2.1 30	OE
185/55R15 82T	6Jx15 ET38	127 5.00	7.6 16.7	2.1 30

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.7SDi

56 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1995 .. 2000]
• Sales regions: Europe, Russia+
• Power: 56 hp | 42 kW | 57 PS
• Engine: 1.7 L, , Diesel

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 82T	33 - 37	118 4.65	7.3 16.2	2.1 30	OE
82T	127 5.00	7.6 16.7	2.1 30

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.9 SDi

63 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1995 .. 2000]
• Sales regions: Europe, Russia+
• Power: 63 hp | 47 kW | 64 PS
• Engine: 1.9 L, , Diesel

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 82T	36 - 40	127 5.00	7.6 16.7	2.1 30	OE
82T	127 5.00	7.6 16.7	2.1 30

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.9D

63 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1995 .. 2003]
• Sales regions: Europe, Russia+
• Power: 63 hp | 47 kW | 64 PS
• Engine: 1.9 L, , Diesel

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 82T	33 - 37	118 4.65	7.3 16.2	2.1 30	OE
82T	127 5.00	7.6 16.7	2.1 30

Volkswagen Caddy II (Typ 9K/9U) [1995 .. 2003] 1.9TDi

89 hp EUDM RUS

• Generation: II (Typ 9K/9U) [1995 .. 2003]
• Production: [1995 .. 2003]
• Sales regions: Europe, Russia+
• Power: 89 hp | 66 kW | 90 PS
• Engine: 1.9 L, , Diesel

• Center Bore / Hub Bore:
• Bolt Pattern (PCD):
• Wheel Fasteners: Lug bolts
• Thread Size:
• Wheel Tightening Torque: unknown

Tire	Rim	Offset Range mm	Backspacing mm inches	Tire Weight kg lb	bar psi
OE 82T	36 - 40	127 5.00	7.6 16.7	2.1 30	OE
82T	137 5.39	7.7 17.0	2.1 30

See Volkswagen Caddy wheel fitment information for other model years:

2026 2025 2024 2023 2022 2021 2020 2019 2018 2017 2016 2015 2014 2013 2012 2011 2010 2009 2008 2007 2006 2005 2004 2003 2002 2001 2000 1999 1998 1997 1996 1995 1992 1991 1990 1989 1988 1987 1986 1985 1984 1983 1982 Page update: 28/10/2025 09:27 Have a question about 1998 Volkswagen Caddy wheel specs? Found a bug? Share your knowledge! Wheel Size Calculator The most comprehensive tire comparison tool suitable for cars, SUVs Tire Glossary Tire terms you can see on this page Center Bore

The size of the hole in the center of a wheel is known as the center bore or centerbore.

Icons Meaning

- Recommended for winter - Run-flat tires - Link comes to the calculator page for comparison - Steel wheels OE - Original Equipment - Tire Pressure - Front axle - Rear axle

Offset

Offset is the distance in millimetres from the centre line of the wheel to the wheel’s mounting face. Given that the mounting face can be either in front of or behind the centreline, the offset can be either neutral, positive or negative.

PCD

The Pitch Circle Diameter (PCD) is the diameter of the circle which passes through the centre of all the studs, wheel bolts or wheel rim holes

Power

hp - Mechanical horsepower kW - Kilowatts PS - Metric horsepower

Backspacing

Wheel backspace is the distance from a wheel's mounting surface to the back edge of the wheel.

Pressure

Tire pressure is a vehicle's recommended cold tire inflation pressure. It is measured in bars or PSI (pounds per square inch).

Regions

A sales region is a global automotive region in which a vehicle was officially sold or is still being sold.

Rim

Ex.: 7J x 15 Rim width (inches) x rim diameter (inches)

Thread Size

ISO standard Ex.: M12 x 1.25 Nominal diameter (mm) x pitch (mm)

UN-series Ex.: 9/16" - 18 UNF Thread size (in) - thread pitch UNF - Unified National Fine Thread

Tire

Example: 215/55 R16 91 T

215 is the tire width in mm 55 is the ratio of profile height to width or simply 'profile'. With the same width, the larger this indicator, the higher the tire will be and vice versa 16 - diameter of the wheel (disk) in inches. (It is the diameter, not the radius!). This is the inner size of the tire or the outer size of the rim 91 - load index. This is the level of maximum permissible load on one wheel T - tire speed index

Weight Wheel Fasteners

The method of attaching a wheel to a hub: wheel nuts or wheel bolts

Wheel Tightening Torque

The torque value specified by the manufacturer for wheel bolts or wheel nuts, which is to be set when tightening on the torque tool (torque setting). A rotational force given in Newton metres (Nm) or foot-pounds (ft-lbs), wheel torque measures lug nut / bolts tightness

Ply Rating Ply rating denotes tire strength and load capacity, based on its layer count. Load Range Ply Rating Max. Load Pressure Original equipment (OE)

The tires included with a new vehicle when it is purchased. OE tires are specifically chosen by the vehicle manufacturer to make the most of the vehicle's performance characteristics.

Load Index / Speed Rating Load Index represents the maximum load a tire can carry, while Speed Rating indicates the maximum safe speed. Load Index Speed Rating Capacity Max Speed
