Guest Guests

27 May, 20187 yr

27 May, 20187 yr

Does anyone have the correct VAG code for Haldex oil for a generation 5? Am hoping to do the change myself, but finding it very difficult to locate the correct type/grade. Most products seem to be for the slightly older gen 4. I am aware that the current one has no filter to replace, and the easiest way to do it is to drop out the pump and clean the built in filter, but for the life of me I can’t seem to source the correct fluid. Thanks.

BATVANVRS FREEDOM

27 May, 20187 yr

27 May, 20187 yr

Try the Briskoda parts section, speak to Mike 01905 346808



[email protected]

Gromle Members

27 May, 20187 yr

27 May, 20187 yr

I can check my receit (spelling?) to see if its listed.



I just had it done on mine.





Guest Guests

28 May, 20187 yr

28 May, 20187 yr

9 hours ago, Gromle said:

I can check my receit (spelling?) to see if its listed.



I just had it done on mine.





That would be very helpful. I assume your car has the newer generation 5 haldex.



nick

26DIPP Members

28 May, 20187 yr

28 May, 20187 yr

https://borgwarnerpumpen.com/en/haldex-oil-ii-v-generation-850-ml9?info=58

VAG PN : G060175A2

The local dealer price is £26.

• 1

Guest Guests

28 May, 20187 yr

28 May, 20187 yr

3 hours ago, 26DIPP said:

https://borgwarnerpumpen.com/en/haldex-oil-ii-v-generation-850-ml9?info=58

VAG PN : G060175A2

The local dealer price is £26.

That’s great, thanks for your help



nick

Petunet Members

29 May, 20187 yr

29 May, 20187 yr

When I had my Haldex oil changed they used VW G 055 175 A2 oil.

https://www.darksidedevelopments.co.uk/products/genuine-audi-high-performance-oil-for-haldex-coupling-g-055-175-a2.html



Remember to tighten the bolts properly:

Edited 29 May, 20187 yr by Petunet

Guest Guests

29 May, 20187 yr

29 May, 20187 yr

I think the picture you have posted is for the 4th generation haldex.

Petunet Members

30 May, 20187 yr

30 May, 20187 yr

Well, this is a picture from my MY17 RS 4x4 Haldex:





Looks pretty much the same to mee.

26DIPP Members

4 June, 20187 yr

4 June, 20187 yr

That is the picture and the real thing of a 4. generation Haldex clutch which is used on the Superb II. Octavias, Fabias...

The difference between G 055 175 A2 and G 060 175 A2 is the size of the container, the first is 1l, the second is 850ml.

• 2 weeks later...

Guest Guests

13 June, 20187 yr

13 June, 20187 yr

Right. Some confusion then. I thought that the Scout had the generation 5 Haldex, which did not have the filter to change as part of the service. If that pic is the gen 4, then I assume mine will be different.

Petunet Members

13 June, 20187 yr

13 June, 20187 yr

So you're saying that your MY15 Scout has newer generation Haldex than my MY17 RS?



• 1

Guest Guests

13 June, 20187 yr

13 June, 20187 yr

All the advertising I have read suggests that the 2015 Scout has the generation 5 Haldex. I’m sure someone on here who knows better than me can offer advice. This is the main reason for the thread, as there is lots of info on the gen 4 and lower, but hardly any for the gen 5.

flybynite Members

13 June, 20187 yr

13 June, 20187 yr

AFAIK all Octavia MK3 4x4 have the 5th Gen Haldex. Mine certainly has.



I think you will find the oil listed is the same for both (G060175A2)



Any doubts I would take it to a dealer

Edited 13 June, 20187 yr by flybynite

Guest Guests

14 June, 20187 yr

14 June, 20187 yr

Ok, so today I have been able to change the Haldex fluid. Having taken the pump out I can confirm that it is the gen 5 version with the gauze filter on the pump itself rather than separate.

have to say I’m glad I did remove the pump as well as drain from the sump, there was a lot of ‘gunk’ sitting in the bottle I used, as well as stuck onto the gauze, so obvious that it was well due for a change. Unfortunately I couldn’t remove the gauze filter, as the 2 torx screws were tight, and with slippery hands it was difficult to get a grip. Have managed to give it a fairly good clean before re fitting.

i used a syringe with a pipe to re fill, difficult but not too bad.

the worst thing was the access, I think next time i will try and find a full lift I can used to get under properly, was shuffling and squeezing to get under, I used ramps, but not really good enough so was a little messy. I remembered to go for a drive to get the content to settle before topping up, so hopefully this will do for another 30k miles or so.

Petunet Members

14 June, 20187 yr

14 June, 20187 yr

Did it look the same as mine?

Guest Guests

14 June, 20187 yr

14 June, 20187 yr

Yes it did, which added to the confusion! I’m sure it is the gen 5 as it had the gauze filter integral to the pump. That and double checking the specs.

Petunet Members

17 June, 20187 yr

17 June, 20187 yr

I have to look the VAG number on the rear diff next time my car is up but I am convinced I have a gen 5 on mine.



This is a picture of a gen 5 Haldex opened:



Guest Guests

20 June, 20187 yr

20 June, 20187 yr

One of the differences I noticed was that the drain hole seemed to be on the same side as the pump, unlike the gen 4 which pictured the drain on the same side as the refill point. There was certainly no sign of separate filter, so definitely gen 5. Have done several hundred miles since change. Have I noticed anything? Not really, but at least I know it has fresh fluid.

Petunet Members

20 June, 20187 yr

20 June, 20187 yr

Did you take a picture of your Haldex?



Guest Guests

21 June, 20187 yr

21 June, 20187 yr

Hi, no, I’m sorry, with all the shuffling and squeezing to get under the last thing I though of was to take a photo! I must remember to do that next time I do any work underneath, if only for my own records.

• 4 weeks later...

pist0nbr0ke Resident Member

18 July, 20187 yr

18 July, 20187 yr

What is the service interval for Haldex?



I've just booked my 4x4 vRS in for its second service at 36k miles and requested they do the DSG oil change at the same time, rather than go back in a few weeks at 40k miles.



Should I be asking them to do the Haldex oil change too?

octavia5 Members

18 July, 20187 yr

18 July, 20187 yr

NO - take to an independent for the Haldex as VAG dealers will only change the oil and not take out the pump to clean it and the filter, arround £110ish at an indy to clean the pump and oil change.

• 1

pist0nbr0ke Resident Member

18 July, 20187 yr

18 July, 20187 yr

3 minutes ago, octavia5 said:

NO - take to an independent for the Haldex as VAG dealers will only change the oil and not take out the pump to clean it and the filter, arround £110ish at an indy to clean the pump and oil change.



Likely to change the car next year at around 45k miles anyway, so not thinking of doing it unless it needs it - is it/will it be actually due?

• 1 year later...

kzolt79 New here

8 March, 20205 yr

8 March, 20205 yr

So, to be sure, is 1 litre of haldex oil enough for Skoda Octavia III 4x4 (2016)?
